JX|8 ShearTec: II Jointer

Motor: 220V 3HP 1 Phase 60hz/12 Amp

CSA: Yes

Bed Size: 8″ x 72″

Infeed Table Pull-Out Extension: 8″

Rabbetting Capacity: 1/2″

Fence Size: 38″ x 4-¾″ Cast Iron

Fence Tilt: ±45/90°

Max. Depth Of Cut: 1/8″

Table Height From Floor: 31″

Safety Bar Shut-Off: Yes

Bracket To Mount Light: No

110V Outlet For Light: No

Bracket To Mount Feeder: No

Dust Port Diameter: 4″

Plug (NEMA 6-20P): Yes

Cutterhead Insert #: 54 x 4-Sided Carbide, 6 Row

Cutterhead RPM: 5500

Cutterhead Diameter: 3-1/8″

Bed Adjustment: Parallelogram

Dimensions Set Up (Approx): 75-1/2″ x 26-1/2″

Base Footprint Dimensions: 32-1/2″ x 15-1/2″

The ShearTec: II features 4-sided solid carbide inserts with a T-shoulder rather than a cone-shaped design, which helps prevent cracking of the inserts.

The ShearTec II cuttherhead comes as standard equipment on JX|8 ShearTec II Jointer. The ShearTec II is a 6-row carbide insert cutterhead that produces a superior surface finish on all woods including challenging hardwoods. The ShearTec II knives and fasteners have a T-step design to maximize clamping force on the knives preventing knife cracking and chatter. The 4-sided carbide insert knives produce a shear cut for flawless results. The ShearTec II cutterhead has deep grooves that make the cutterhead very quiet and improve shaving ejection. The 4-sided knives can be rotated for a new cutting edge without need for a knife setting jig.
