CO2 Lasers
SmartShop® Laser | EX-C
Acrylic - Wood - Budget Friendly
The Laguna SmartShop® Laser|EX-C is a powerful CO2 laser cutter and engraver that comes packed with user-friendly features to make operation a breeze. The EX-C comes with a specialized Camera System that is designed to read registration marks and triangulate where the prints are on the material. With a 150W laser tube packed inside, this machine has no trouble with thick acrylic or other materials.
Features:
- Optical Recognition System
- Reci Laser Tube 150W
- Chiller, Compressor & Exhaust Fan Included
- Laptop & Light Burn Software Included
- Honeycomb Table Included
- Knife Table Included
- 2-Day Installation Included
$19,500
Training available upon request Via Zoom
Description
Reci Laser Tube: 150W
Table Dimensions: 36″ x 51″
Lift Table: Up To 7
WiFi Enabled
Weight: 1050 lbs
Precision Drive Motors
HiWin Linear Guide Rails
Japanese Electronic Components
Auxiliary Exhaust Fans & Dust Port
Camera Specs
- Camera registration software supports Ai and DXF formats
- Software is RD Mark Vision software for printed material such as acrylics and woods
- RD Vison Software is provided for embroidery cutting and fabric or paper products
- Traditional RD Works for standard laser cutting
- Does NOT have auto focus
- Pass thru table
- Small parts collection tray
Videos
-
Woodworking Beer Flight Gift For Father’s Day | CO2 Laser & CNC Router
-
Laser Engraving A Custom Mother’s Day Jewelry Box | CO2 Laser
-
Laser Engraving A Mini Keg Growler With A Rotary Turner | CO2 Laser
-
How To Engrave Custom Wall Art On A CO2 Laser | Software Tutorial
-
Introducing The New Laguna RotoBoss Rotary Turner | CO2 Laser
-
Laser Engraving A Custom Whiskey Glass And Stone Set | CO2 Laser
-
How To Get Up To 14 Inches of Clearance On Your CO2 Laser | Laser EX and MX
-
Laser Cutting An Acrylic Inlay On A CO2 Laser | Sign Making
-
Laser Engraving Recipes For A Personalized Cutting Board | CO2 Laser
-
How to Design and Laser Engrave an Image with a CO2 Laser | Software Tutorial
-
Organizing Vinyl Records With Laser Cut And Engraved Record Dividers | CO2 Laser
-
Laser Cutting A Custom 3D Acrylic Skateboard Sign | Sign Making On A CO2 Laser
Manual
CO2 Laser Cutter / Engraver Settings For Common Materials
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 25 | 350 | .065 | ANY |
| 100W | 20 | 350 | .065 | ANY |
| 150W | 15 | 350 | .065 | ANY |
| Cutting Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 80 | 10 | N/A | 1/4″ |
| 100W | 75 | 15 | N/A | 1/4″ |
| 150W | 65 | 20 | N/A | 1/4″ |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap(mm) | Thickness |
| 65W | 35 | 325 | .065 | ANY |
| 100W | 20 | 325 | .065 | ANY |
| 150W | 15 | 325 | .065 | ANY |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 25 | 350 | .065 | ANY |
| 100W | 20 | 350 | .065 | ANY |
| 150W | 15 | 350 | .065 | ANY |
| Cutting Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 60 | 25 | N/A | 1/8″ |
| 100W | 55 | 25 | N/A | 1/8″ |
| 150W | 40 | 25 | N/A | 1/8″ |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 35 | 350 | .065 | ANY |
| 100W | 25 | 350 | .065 | ANY |
| 150W | 20 | 350 | .065 | ANY |
| Cutting Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 60 | 25 | N/A | 1/8″ |
| 100W | 55 | 25 | N/A | 1/8″ |
| 150W | 40 | 25 | N/A | 1/8″ |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 35 | 350 | .065 | ANY |
| 100W | 25 | 350 | .065 | ANY |
| 150W | 20 | 350 | .065 | ANY |
| Cutting Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 80 | 10 | N/A | 1/4″ |
| 100W | 70 | 15 | N/A | 1/4″ |
| 150W | 65 | 20 | N/A | 1/4″ |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 30 | 350 | .065 | ANY |
| 100W | 25 | 350 | .065 | ANY |
| 150W | 20 | 350 | .065 | ANY |
| Cutting Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 85 | 10 | N/A | 1/4″ |
| 100W | 75 | 15 | N/A | 1/4″ |
| 150W | 70 | 20 | N/A | 1/4″ |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 25 | 350 | .065 | ANY |
| 100W | 20 | 350 | .065 | ANY |
| 150W | 15 | 350 | .065 | ANY |
| Cutting Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 70 | 15 | N/A | 1/4″ |
| 100W | 60 | 15 | N/A | 1/4″ |
| 150W | 50 | 15 | N/A | 1/4″ |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 65 | 350 | .065 | ANY |
| 100W | 40 | 350 | .065 | ANY |
| 150W | 27 | 350 | .065 | ANY |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 27 | 325 | .065 | ANY |
| 100W | 25 | 325 | .065 | ANY |
| 150W | 20 | 325 | .065 | ANY |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 40 | 275 | .065 | ANY |
| 100W | 25 | 275 | .065 | ANY |
| 150W | 18 | 275 | .065 | ANY |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 25 | 350 | .065 | ANY |
| 100W | 18 | 350 | .065 | ANY |
| 150W | 15 | 350 | .065 | ANY |
| Cutting Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 85 | 10 | N/A | 1/8″ |
| 100W | 75 | 12 | N/A | 1/8″ |
| 150W | 70 | 15 | N/A | 1/8″ |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 35 | 325 | .065 | ANY |
| 100W | 20 | 325 | .065 | ANY |
| 150W | 15 | 325 | .065 | ANY |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 30 | 325 | .065 | ANY |
| 100W | 20 | 325 | .065 | ANY |
| 150W | 15 | 325 | .065 | ANY |
| Cutting Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 15 | 20 | N/A | 1/100″ |
| 100W | 15 | 25 | N/A | 1/100″ |
| 150W | 15 | 30 | N/A | 1/100″ |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 25 | 350 | .065 | ANY |
| 100W | 20 | 350 | .065 | ANY |
| 150W | 15 | 350 | .065 | ANY |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 30 | 350 | .065 | ANY |
| 100W | 20 | 350 | .065 | ANY |
| 150W | 15 | 350 | .065 | ANY |
| Cutting Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 85 | 10 | N/A | 1/8″ |
| 100W | 75 | 12 | N/A | 1/8″ |
| 150W | 70 | 15 | N/A | 1/8″ |
| Engraving Watts | Power % | Speed(mm/s) | Interval/Scan Gap (mm) | Thickness |
| 65W | 60 | 25 | N/A | 1/4″ |
| 100W | 55 | 25 | N/A | 1/4″ |
| 150W | 40 | 25 | N/A | 1/4″ |
